How to customize non-standard rotary joints

Various industries use different specifications and sizes of rotary joints, so now ordinary conventional rotary joints can no longer meet the requirements of equipment applications, and it is necessary to customize them according to the actual situation for customers. So what is a non-standard rotary joint? Today, the editor will give you a detailed explanation to give you a better understanding:

1、 When customizing non-standard rotary joints, four parameters must not be omitted: medium, temperature, pressure, and speed, which need to be accurately labeled.
2、 Understanding the use of equipment during installation, as the attributes of equipment vary in each industry, so the requirements for functionality are also different. The selection of that type of equipment is a reference for selection. The installation method should be understood, and both horizontal and vertical information should be provided to the customer before customization.
3、 The connection methods of equipment are generally divided into flange and threaded connections, and threaded connections are further divided into rotary and threaded types.
4、 The above is what needs to be understood before customizing non-standard rotary joints. Below is a summary of the differences between non-standard and standard:
1. Determine whether the standard joint can meet the equipment operating conditions;
2. Whether the dimensions of the relevant interfaces for connecting and assembling are in compliance.
Summary: If none of the above requirements can be met, changes can be made based on the standard joint size. Technical communication and exchange should be conducted to design the drawings of non-standard rotary joints according to the customer’s requirements. After both parties confirm the drawings and sign the contract, they can be handed over to the production workshop for processing arrangement.
