High speed rotary joint

High speed rotary joint is an industrial key component used to transport fluid media (such as water, oil, gas, steam, etc.) from fixed pipelines to rotating equipment. Its core function is to ensure continuous and stable transmission of the medium while preventing leakage, streaming, or external pollution, and adapting to high-speed operating conditions.

Origin: Shandong
Customized processing: Yes
Whether to import: No
Material: Aluminum alloy, stainless steel
Installation method: flange thread
Speed: 3800r/min
Pressure: ≤ 3.0MPA
Temperature: ≤ 100 ℃
Media: gas, oil, vacuum, water, nitrogen, coolant, etc
Non standard customized products are for personal customization. Once produced, returns and exchanges are not supported. Please carefully review or communicate with customer service before placing an order.
If there are special requirements, they can be customized. The delivery time will increase by 3-15 days and the cost will increase by 5% -50%. Most of our basic accessories are standardized, modular, and non-standard customized, which can greatly reduce costs and delivery time.
Single channel coolant or MQL (oil mist);
Closed sealing, automatic production line for similar applications;
Full flow design, no debris or burr blockage;
The bearing support has a threaded rotor for easy installation;
Maze system and large leakage port are used to protect ball bearings;
Balanced mechanical seal, made of silicon carbide, can extend its service life even under harsh operating conditions;
The anodized aluminum shell and stainless steel rotor are corrosion-resistant.
