1101-265-239 rotary joint

1101-265-239 rotary joint is a standard model of the 1100 series rotary joint, used for sealed transmission of single media (such as coolant, steam, oil, etc.) in rotating equipment. The interface is G1/4 “radial (20mm diameter), suitable for medium and high speed, medium pressure working conditions

Working parameters:
Medium: MQL, coolant
Rotor connection: 16×1.5 LH, 17.993 mm pilot
Supply connection: 3/8 “-19 PT
Coolant flow rate: 24.3 l/min
Coolant pressure: 103.4 bar
Coolant temperature: 71 ° C
MQL flow rate: 49.8 l/min
MQL pressure: 10 bar
MQL temperature: 71 ° C
Single channel for coolant or MQL
Closed seal for automatic lines and similar applications
Full flow design, unobstructed passage, avoiding residual impurities
The threaded rotor supported by bearings is easy to install
Deep groove ball bearings operate smoothly
Maze structure and multiple large leakage ports to protect ball bearings
The balanced mechanical seal uses silicon carbide, which has a long service life, even under harsh operating conditions
Anodized aluminum parts for corrosion resistance
