1005-000-037 rotary joint is a single channel self-supporting pneumatic/hydraulic rotary joint designed for medium transmission of air or low viscosity hydraulic oil in medium to low speed and narrow space conditions. It adopts balanced mechanical seals and lifelong lubrication bearings, and can be installed without external brackets.
1005-000-037 rotary joint is a single channel self-supporting pneumatic/hydraulic rotary joint designed for medium transmission of air or low viscosity hydraulic oil in medium to low speed and narrow space conditions. It adopts balanced mechanical seals and lifelong lubrication bearings, and can be installed without external brackets.
Model: SD1005-000-037
Customized processing: Yes
Whether to import: No
Installation form: flange thread
Brand: SD
Material: Stainless steel
Scope of application: Rotating joints for construction machinery
Temperature resistance: 60 ℃
Pressure: 1.5-3MPA
Speed: 2000-3800 RPM
Media: gas, compressed air, water, hydraulic oil, coolant
Non standard customized products are for personal customization. Once produced, returns and exchanges are not supported. Please carefully review or communicate with customer service before placing an order.
If there are special requirements, they can be customized. The delivery time will increase by 3-15 days and the cost will increase by 5% -50%. Most of our basic accessories are standardized, modular, and non-standard customized, which can greatly reduce costs and delivery time.
Made of stainless steel with strong corrosion resistance;
Internal bearings use NSK bearings;
Using imported silicon carbide ceramic rings, the sealing accuracy, compression resistance, and high temperature resistance are better than graphite rings.
A rotary joint is a sealing device that connects stationary pipelines and rotating equipment, achieving leak free fluid transmission under 360 ° rotation. It allows fluid media to flow smoothly between fixed pipelines and rotating machines, and is a key component in industrial equipment
