High voltage quick connector
Discover high-voltage quick connectors designed for EVs and industrial machinery. Features IP67 waterproofing, up to 500A current capacity, and HVIL safety mechanisms. Ensure reliable, spark-free power transmission in harsh environments.
- mediumHydraulic oil
- Operating Temperature-20℃--+80℃
- work pressure21MPa
- maximum speed3000r/min
High voltage quick connector
Overview
A high voltage quick connector (HVQC) is a fast-plug electrical connection component designed for high-voltage systems. It enables rapid assembly and disassembly of high-voltage circuits without professional tools, widely used in new energy vehicles, energy storage systems, charging piles and other high-voltage power equipment.
feature
Split type combination structure, convenient for quick on-site maintenance
Two precision imported deep groove ball bearings support smooth rotation
The shaft core has undergone special treatment to ensure sufficient wear resistance
Two precision imported deep groove ball bearings support smooth rotation
The shaft core has undergone special treatment to ensure sufficient wear resistance
Advantage
Independent channel, high voltage resistance
Self detachable, quick replacement of repair kit
Imported seal, wear-resistant, long service life
Self detachable, quick replacement of repair kit
Imported seal, wear-resistant, long service life
Product Parameter
| Parameter | Specification |
|---|---|
| Rotational Speed | 3000 r/min |
| Working Pressure | 21 MPa |
| Operating Temperature | −20 ℃ to +80 ℃ |
| Working Medium | Hydraulic Oil |
