gas-liquid electric integrated slip ring

what is Gas-liquid electric integrated slip ring

Gas liquid electric integrated slip ring is a rotating joint that integrates conductive slip ring, gas slip ring, and liquid slip ring together. It can synchronously transmit current, signal, gas, and liquid while the equipment rotates 360 °, avoiding pipeline entanglement and saving installation space.

Gas electric combination slip ring is applied in industrial machinery – combination machining center machine tools, rotary indexing tables; Heavy equipment turrets, cable reels, testing equipment; Packaging machine, stacker crane, magnetic clutch, process equipment; Rotating sensors, emergency lighting, robot technology; Exhibition/Display Equipment, Medical Equipment.

Gas-liquid electric integrated slip ring Characteristics：

Transmission of power supply, control signal power supply, switch signal, micro electric quantity signal required for instrument and computer automatic control+fiber optic+mercury+servo motor signal; Transmission of hydraulic power, multiple selection; Capable of transmitting compressed air, negative pressure, positive pressure, cooling water, hot oil and other media 360 degrees; Hollow and solid structural rotary joints are available for selection.
■ Transmission power supply, Inter Bus,Can-Bus,Profibus,RS422,RS485,PLC， Electromagnetic valve signal, encoder signal, etc
■ Can mix and transmit hydraulic power, with multiple options (such as providing hydraulic oil for hydraulic cylinders)
■ Multiple options for transmitting compressed air and other gases, cooling water, coolant, etc
Modular design to meet higher current, speed, appearance and other requirements
Diversified appearance, supporting more installation requirements, high protection level: oil proof, dustproof, moisture-proof.
Performance Parameters
Gas liquid electric hybrid conductive slip ring, also known as gas liquid electric hybrid rotary joint, is a combination of pneumatic slip ring, waterproof slip ring, and electric slip ring. It is a series of conductive slip ring products developed by DaNeng Electromechanical specifically for devices that require 360 ° rotation for conduction and simultaneous gas (vacuum, compressed air, etc.), liquid (hydraulic oil, coolant, water, etc.), and signal (Ethernet, USB, high-definition video, private server motors, and various control signals) transmission. The integrated slip ring produced by SD can be used for various high-tech automation equipment that requires mixed transmission of gas-liquid electricity, especially in harsh environments such as humidity and seawater.

Gas-liquid electric integrated slip ring Typical Applications:

Industrial machinery – machining centers, lifting equipment towers, CNC machine tools, etc
Steel ladle transport turntable, rotating worktable, etc
optional item
360 degree rotation simultaneously transmits gas, liquid, and electrical
● Supports 1-8 gas or liquid channels
● Support 1-56 electrical circuits
Customization of liquid or gas pipe sizes according to customer requirements
● Can transmit water, hot water, coolant, steam and other media
Solid or through-hole options available
SD  MAPH104 series (1 inlet and 4 outlets/liquid+electric integrated slip ring)
·MAPH104 gas/liquid+electric rotary adapter, compatible with M5, G1/8, G1/4, G3/8, G1/2 pipe diameters
·And it can mix power lines, signal lines, Ethernet USB、 Industrial bus, control line, solenoid valve, induction line, etc
·The standard is flange installation form, and can be customized with hollow shaft installation of gas/liquid+electric integrated slip ring and rotary joint
·The media that can pass through include compressed air, hydrogen, nitrogen, chemical mixtures, steam, cooling water, hot water, hot oil, petroleum, sulfuric acid, beverages, etc
The gas electric integrated rotary joint is a precision gas path rotary joint that transports gas-liquid media from non rotatable gas pipes to dynamic rotating sealing devices. It includes compressed air, hydrogen, nitrogen, chemical mixtures, steam, cooling water, hot water, hot oil, petroleum, sulfuric acid, beverages, and other gas-liquid components, which can be combined for conduction and transmission of various control signals.
The gas-liquid electric combination rotary joint, also known as the gas-liquid electric hybrid conductive slip ring, is a collection of pneumatic slip rings, waterproof slip rings, and electric slip rings. It should be able to continuously transmit compressed air, cooling water, hydraulic oil or other fluid media, while also achieving continuous transmission of data, signals or power supply. For example, a series of rotary joint products developed for devices that require 360 ° rotation for conductivity and simultaneous gas (vacuum, compressed air, and other gases), liquid (hydraulic oil, coolant, water, and other liquids), and signal (Ethernet, USB, high-definition video, servo motors, and various control signals). This combination rotary joint can be used for various high-tech automation equipment that requires mixed transmission of gas-liquid electricity, especially in harsh environments such as humidity and seawater. Widely used in wind turbines, work turntables, industrial robots, construction machinery, pharmaceutical filling and other devices that require 360 degree rotation for conductive or combined transmission of gases and other media. Features: 360 degree rotation for simultaneous transmission of gas, liquid, and electricity. ·Supports 1/2/4/8 gas or liquid channels ·Support 1-48 electrical circuits ·We can customize the size of liquid or gas pipes according to customer requirements, and can transmit water, hot water, coolant, steam and other media ·Solid or through-hole options are available.
